GRAVITY BRED

When gravity calls, you can either fight against it or commit to the ride. Don’t be afraid to take things too far, push harder, and dare where others hesitate. Relentless evolution is the only way forward, because the finish line is just the beginning of something greater. Rallon is a new breed of gravity bike, forged through years of development in the lab and on the race track. Its low center of gravity delivers unmatched stability, precision, and control at race speed, while supple suspension maximizes traction and opens up new line choices. And because no two tracks—or riders—are the same, Rallon offers unparalleled adjustability, letting you fine-tune performance for every ride.

Features

  • Headset Adjust: The headset angle is easily adjustable using the offset headset cup. The possibility of regulating +/- 0.75º allows you to slip into a more slack position for steeper tracks or more aggressive runs.
  • Flip Chip: Using the flip chip, you can change the shock progressivity around 5% and swap between the High and Low positions. For more stability on fast tracks, pop into Low. For increased pedalling clearance, go High. 0.5 Head Angle Change and 7mm BB Drop Change
  • Weighted Bottom Bracket: Install any of the included weights onto the GravityLink via its threaded holes to lower the center of gravity and improve composure.

Specification

Material Orbea Rallon OMR (Carbon)
Travel 170mm
Shock Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x62.5mm
Headset Alloy 1-1/2", Black Oxidated Bearing
Shock Support Enduro 29 GravityLink (assembled) + Enduro Mullet GravityLink (extra)
Chainguide e*thirteen CL55 30-36t black
Stem OC Mountain Control MC11 Alu SL, 0º
Computer Mount OC Computer Mount CM-05, Garmin/Sigma
Storage Accesories Containers
Tools MT-20 FLP Multitool 2/3/4/5mm hex
Seat Clamp Diameter 34.9mm
Seat Post Diameter 31.6mm
